Press Sheet Stamping Hydraulic HPU 1000-1800/1150

Price

Contact us for price

orCall +91 9819336548

Specifications

ManufacturerSMG
ModelHPU 1000-1800/1150
Year1982
ConditionUsed
Stock NumberMA1732
Capacity tons1000
Item conditionGood working condition, full complete

Description

Total force : 1000 tons.

Slide retraction force : 590 kN,

Ram stroke : 400 mm,

Distance table / ram : 1200 mm,

Ram surface (width / depth) : 1800/1150 mm,

Clear width between the uprights : 1810 mm,

Table clamping surface (width / depth) :1800/1150 mm,

Table ejector force : 800 kN,

Table ejector stroke : 125 mm,

Table ejector surface (width / depth) : 1260/700 mm,

Drive power : 90 kW,

Pump output : 360/1500 l/min, U/min,

Rapid speed (down / up) : 400/244 mm/s,

V max . : 16/23, 5/47 mm/s,

V nominal pressure : 8.5/13/25 mm/s,

Ram — ejector hydr. (number / stroke) : 1 x 50/2000 mm/kN,

Plunger pad area (width / depth) : 1250/760 mm.
