Press Hydraulic Hydrotek

Capacity : 2000 tons,

Stroke : 2000 mm,

Lifting capacity : 80 tons,

Open Height : 2000 mm,

Cushion : 700 tons,

Cushion lifting : 35 tons,

Length of day light : 2500 mm,

Cushion Stroke : 500 mm,

Working Pressure : 253 Kgf/Cm2,

Cushion working pressure : 236 Kgf/Cm2,

Descending Speed : 200-250 mm/sec,

Pressing Speed : 12 (at 2000-500 ton) / (at 2000 ton),

Ascending Speed : 150-190 mm/sec,

Cushion ascending : 50-80 mm/sec,

Bolster area : 6000 x 2500 mm,

Moving Bolster :

Moving speed : 40-60 mm/sec,

Geared motor : 5.5 Kw,

Moving stroke : 2550 mm,

Cushion Pad area : 5000 x 1600 mm,

Hyd pump : 550 L/mm,

Main Motor : 160 Kw x 1EA,

Oil-Tank Capacity : 3600 liter,

Noise degree : 85.5 dB(A),

Operation Method : Manual & 1 - Cycle Auto,

Power Voltage : AC380V x 3⌀ x 60 Hz,

Weight : 350 tons.
