Lathe Vertical Turning Hwacheon HVT4550M

Price

Contact us for price

orCall +91 9920651051

Specifications

ManufacturerHwacheon
ModelHVT4550M
Year2015
ConditionUsed
Stock NumberMA2104
Item conditionGood condition
Capacity tons5000

Description

Swing : 5000 mm,

Max working dia : 5000 mm,

Height : 2500 mm,

Loading capacity : 40000 kgf,

Table size : 4500 mm,

Speed : 1-50 rpm,

Max. Torque : 139[14,183kgf] KN-m,

x travel : -250 +4100 mm,

z travel : 1500 mm,

w travel : 2000 mm,

Feed Rate:

Rapid feed rate : 6/6/0.5 m/min,

Cutting feed rate: 1-3000 mm/min,

Table main motor : 145/105 Kw,

Milling main motor : 30/22 Kw,

Feeding motor : 7.75/7.75/2-7.75 Kw.
