Press Cold Forging MML2-1250-1.5-400
Sold
Specifications
| Manufacturer | Abe Seiki,Japan |
| Model | MML2-1250-1.5-400 |
| Year | 2014 |
| Condition | Used |
| Stock Number | MA2132 |
| Item condition | Good working condition, under power |
| Capacity tons | 1250 |
Description
Capacity : 1250 tons,
Rated force travel : 20 mm,
Work capacity at stroke rate : 200 kJ / 25 min-1,
Stroke rate : 25-50 min-1,
Setup stroke rate : ab 3-10 min-1,
Max. flywheel speed : 951 min-1,
Drive motor : 180 kW / 3180 min-1,
Distance between uprights : 920 mm,
Slide stroke : 400 mm,
Slide adjustment : 15 mm,
Width x Depth : 1560 x 800 mm,
No. of pressure pins : 5,
Integrated in to stage : 1, 2, 3, 4, 5,
Ejector path Mechanical : 100 mm,
Single force : 100 kN,
Total force : 260 kN,
Installation height from clamping surface : 1000 mm,
Stroke down, adjustment up
Bed (Width x Depth) : 1500 x 800 mm,
No. of pressure pins : 5,
Ejector path mechanical : 125 mm,
Single force : 320 kN,
Total force : 800 kN,
Total weight : 145 tons.
