Press Sheet Stamping Mechanical TMP Voronezh Russia

Capacity : 3150 tons,

Slide distance to its extreme lower position where the press develops its nominal capacity : 12 mm,

Connecting rod : 2 N,

Slide stroke : 500 mm,

Strokes per minute : 12,

Single strokes per minute : 9,

Die space : 1000 mm,

Die space adjustment in the ram : 300 mm,

Table Dimensions :

L to R : 3500 mm,

F to B : 1800 mm,

Uprights opening dimensions : 2000 x 1700 mm,

Slide Dimensions :

L to R : 3500 mm,

F to B : 1600 mm,

Height of the mobile table : 630 mm,

Height of the table : 320 mm,

Pneumatic cushion in the table :

Number : 2 N,

Stroke : 200 mm,

Power (P=0,5 MPA) : 140 tons,

Overall dimensions of the 2 cushions :

L to R : 2675 mm,

F to B : 1125 mm,

Max. die weight on the ram (included bolster plate) : 10 tons,

Total die weight : 150 tons,

Main motor :

Power : 200 Kw,

Compressed air pressure : 0.5 MPA,

Compressed air consumption each cycle : 20 DM3,

Overall dimensions :

L to R : 5500 mm,

F to B : 6900 mm,

Press height : 12615 mm,

Height above floor level : 9385 mm,

Press total weight : 468 tons.
