5 tons Manipulator Russian MK-5-66

Railbound Forging Manipulator

Capacity : 5 tons,

Hoisting tongs : 120 kN. m,

Maximum diameter of the tongs rotation circle : 1280 mm,

Distance from the end face of the tongs jaws to the frame : 2400 mm,

Maximum diameter of the tongs opening : 720 mm,

Minimum height of the arm C. I. above the rail head : 950 mm,

Maximum height of the arm parallel lifting : 500 mm,

Tongs rotations per minute : 14.6

Maximum load moment in clamp : 12 t.m

Max. workpiece diameter : 550 kw,

Distance from floor level to trunk axis:

Up : 1440 mm,

Down : 290 mm,

Dimension :

Length : 7670 mm,

Width : 4320 mm,

Height : 3340 mm,

Capacity of motor : 105 kW.

Manipulator speed : 0.67 m/s,

Weight : 53 tons.
