3000 tons Press Brake Hydraulic CNC Aliko 12800 x 3000 to

Capacity : 3000 tons,

Chamfer Length : 14000 mm,

Distance between columns : 10500 mm,

Control : CYBELECCNC 7000 m. Grafik,

Table width : 1000 mm,

Stroke 1300 mm,

Min./Max. Distance between table and ram : 1800 mm,

Controlled axis : Y1; Y2; X1; X2,

Weight of the machine ca. mind. : 465 tons,

Dimensions of the machine ca. : 14600 x 4200 x 7200 mm.

Throat depth : 700 mm

Controlled axes : Y1, Y2, X1, X2

Dimensions (length x width x height) :

Foundation depth for table : 3400 mm

Foundation depth for stand : 1700 mm,

Dimensions of the individual components for transportation:

-Table : 14020 x 4270 x 910 mm,

Weight approx. : 125 tons,

-Top section: 15240 x 4060 x 910 mm,

Weight approx. : 120 tons,

-2 side stands : 7620 x 3550 x 1530 mm,

Weight approx. : 90 tons each,

-Lower tool : 15240 x 1220 x 1220 mm,

Weight approx. 40 tons,

2 pcs. Container 40 for cylinder, electrics and various attachments

Control system was renewed in 2012.
