Sheet Stamping Line Mechanical Dongshin 600T-400T-300T-300T
Specifications
| Manufacturer | Dongshin |
| Model | 600T-300T-300T-300T |
| Year | 2006 |
| Condition | Used |
| Stock Number | MA3108 |
| Item condition | Good condition |
| Capacity tons | 600 |
Description
Tendem Line for DONGSHIN 600T-400T-300T-300T
Tandem Line
1) Header / Dongshin New 2006 DCLP600 Ton
2) Ssangyong DA400 Ton
3) Dongshin DCLP300 Ton
4) Donshin DCLP300 Ton
With Moving Bolstert + Robot
1) Dongshin (Korea) DCLP600 Head Press 600 Ton, 2006
Capacity : 600 tons,
Stroke of length : 700 mm,
No. of stroke per min. : 24 SPM,
Die height : 1200 mm,
Slide of adjustment : 500 mm,
Slide of are : 3000 x 1600 mm,
Bolster of are : 3000 x 1600 mm,
Die cushion : 100 tons,
Die cushion stroke : 250 tons,
Die cushion pad size : 1750 x 1100 mm,
Remark : 700 tons written
Robot : Yaskawa
Moving Direction : Left.
2) Ssangyong (Korea) DA400 2nd Press 400 Ton, 1993
Capacity : 400 tons,
Stroke of length : 300 mm,
No. of stroke per min., : 14-24 SPM,
Die height : 900 mm,
Slide of adjustment : 200 mm,
Slide of are : 2600 x 1500 mm,
Bolster of are : 2600 x 1500 mm,
Die cushion : 48 (24x2) tons,
Die cushion stroke : 150 tons,
Die cushion pad size : 2000 x 950 mm,
Robot : Fanuc,
Robot Model : R-2000iA,
Moving Direction : Left.
3) Dongshin (Korea) DCLP300 3rd Press 300Ton - New 2006
Capacity : 300 tons,
Stroke of length : 600 mm,
No. of stroke per min., : 24 SPM,
Die height : 1200 mm,
Slide of adjustment : 500 mm,
Slide of are : 3000 x 1600 mm,
Bolster of are : 3000 x 1600 mm,
Die cushion : 30 tons,
Die cushion stroke : 250 tons,
Die cushion pad size : 1750 x 850 mm,
Remark : 400 ton written
Robot : Fanuc,
Robot Model : R-2000iA,
Moving Direction : Left.
4) Dongshin (Korea) DCLP300 4th Press 300Ton - 2006
Capacity : 300 tons,
Stroke of length : 600 mm,
No. of stroke per min., : 24 SPM,
Die height : 1200 mm,
Slide of adjustment : 500 mm,
Slide of are : 3000 x 1600 mm,
Bolster of are : 3000 x 1600 mm,
Die cushion : 30 tons,
Die cushion stroke : 250 tons,
Die cushion pad size : 1750 x 850 mm,
Remark : 400 tons written,
Robot : Fanuc,
Robot Model : R-2000iA,
Moving Direction : Left.
