Lathe Vertical Turning Titan SC-33

Swing : 3300 mm,

Max. work-piece height : 2300 mm,

Max. work-piece weight : 18 tons,

-Table :

Diameter : 3000 mm,

Speed range : 1.02-92 rpm,

Increased speed : 1.5-150 rpm,

-Cross-rail :

Vertical travel : 2100 mm,

Rapid positioning feed : 400 mm/min,

-Vertical rail heads :

Vertical ram travel : 760 mm,

Right rail head : 1000 mm,

No. of feed steps : 16,

Feed range : 0.05-5 mm/rev,

Rapid positioning feed : 2500 mm,

Head tilting angle : +/-35 deg,

Tool holder diameter : 80 mm,

-Horizontal side rail head :

Horizontal travel : 1000 mm,

No. of feed steps : 16,

Feed range : 0.05-5 mm/rev,

Rapid positioning feed : 2500 mm,

-Slow feedbox :

Table slow feeds : 1-360 deg/min,

Table slow feed motor torque : 45-55 Nm,

Main motor : 55 kW, D.C.,

-Machine dimensions :

Length : 5600 mm,

Width : 5300 mm,

Height : 5400 mm,

Machine weight : 48 tons.
