Press Cold Extrusion K0034
Specifications
| Manufacturer | Barnaul, Russia |
| Model | K0034 |
| Year | 1982 |
| Condition | Used |
| Stock Number | MA0361 |
| Item condition | Good working condition, full complete |
| Capacity tons | 250 |
Description
Capacity : 250 tons,
Ram stroke : 200 mm,
Strokes per minute : 32,
Adjustment : 15 mm,
Dimensions of the bolster plate :
Left-to-right : 800 mm,
Front-to-back : 800 mm,
Max. single-stroke engagements : 20/1 min,
Maximum tools shut-height : 490 mm,
Upper ejector stroke : 20...25 mm,
Upper ejector capacity : 10 MN,
Lower ejector stroke : 110 mm,
Lower ejector capacity : 30 MN,
Main drive : 75 kW,
Press dimensions : 2950 x 1950 x 4090 mm,
Press weight : 21.5 tons.
