Press Sheet Stamping Hydraulic Ryazan Russia

Sold

Specifications

ManufacturerAbe Seiki,Japan
ConditionUsed
Stock NumberMA0422
Item conditionGood Condition
Capacity tons630

Description

Capacity : 630 tons,

Maximum traverse stroke : 600 mm,

The pressure of the fluid in the system : 200 kg/cm2,

Reverse stroke force : 50 tons,

The force of the ejector : 50 tons,

Ejector stroke: 250 mm,

Greatest distance between table and traverse : 1325 mm,

Distance between columns :

from left to right: 840 mm,

front to back: 360 mm,

Table size :

from left to right: 800 mm,

front to back: 900 mm,

The dimensions of the entire setup :

Length: 1680 mm,

Width: 1800 mm,

Height over floor level : 4830 mm,

Press weight : 17.1 tons.
