Lathe Vertical Turning CNC SKIQ8BCNC

Price

Contact us for price

orCall +91 9920651051

Specifications

ManufacturerTos Czech
ModelSKIQ8BCNC
Year1989
ConditionUsed
Stock NumberMA0592
Item conditionGood condition dismantled
Capacity tons800

Description

CNC TOS vertical lathe SKIQ8BCNC with Tesla NS642 :

Face plate diameter : 800 mm,

Max. workpiece diameter : 1000 mm,

Max. workpiece height : 750 mm,

Max. diameter of external working : 1000 mm,

Z axe : 630 mm,

Face plate revolutions : 1 5 – 500 rpm,

Main motor output : kW 30 (40),

Machine dimensions :

Length : 4900 mm,

Height : 3830 mm,

Width : 4485 mm,

Machine weight : 16 tons,

can supply one more electrical cabinet for spareparts.

the machine has spindle for the drilling and grinding.
