Press Sheet Stamping Mechanical PKZZI1250

Price

Contact us for price

orCall +91 9920651051

Specifications

ManufacturerWMW Erfurt,Germany
ModelPKZZI1250
ConditionUsed
Stock NumberMA1050
Item conditionGood Condition
Capacity tons1250

Description

Straight side Sheet Stamping Press :


Max. slider force at the distance of 12,5 mm in the lower dead point : 1250 tons,

Slider force at the distance of 250 mm in the lower dead point : 350 tons,

Number of single strokes per minute : 11,

Slider stroke : 630 mm,

Slider adjustment : 630 mm,

The closed height : 1165 mm,

Table pillow :

-Max. stroke : 250 mm,

-Stroke adjustment : 250 mm,

-Max. holding force : 250 tons,

-Max. ejection force : 40 tons,

Table dimensions : 4000 x 1800 mm,

Bolster dimensions : 3950 x 1800 mm,

Table gap : 3750 x 1300 mm,

Main motor power : 132 kW,

Stay spacing : 4000 mm,

Press weight : 215 tons,

Weight of a table in assembly with an exhaust pillow and a plate of a pusher : 42.6 tons,

Weight of a table (without built in details) : 27.4 tons,

Weight of an exhaust pillow : 3000 kg,

Weight of a plate of a pusher : 5400 kg,

Weight of a lateral rack in assembling : 8000 kg,

Weight of a cross-arm in assembling : 44000 kg,

Weight of a cross-arm without built in details : 24.8 tons,

Weight of the top part of a cross-arm : 7800 kg,

Weight of a shaft of a flywheel with a pine forest with a muff and brakes : 16.9 tons,

Weight of a slider in assembling : 33.6 tons,

Weight of coupling bolts : 3400 kg.
