Press Fineblanking Mechanical HFA6300

Price

Contact us for price

orCall +91 9819336548

Specifications

ManufacturerSMG Feintool
ModelHFA6300
Year1989
ConditionUsed
Stock NumberMA1142
Item conditionGood working condition
Capacity tons630

Description

Total force (nominal): 400-630 tons,

Slide stroke: 20-100 mm,


V-RING

Nominal force: 320 tons,

Slide stroke: 40 mm.


OTHER SPECIFICATIONS

Max. daylight: 400 mm,

Cutting force: 180-585 tons,

Max. second movement: 27 mm,

Close speed: 120 mm/s,


TOOL AREA

Lower table width: 900 mm,

Lower table depth: 900 mm,

Upper table width: 900 mm,

Upper table depth: 1260 mm,

Tool shut height: 320-400 mm,

Clamping area distance: 500 mm,

Material distance from upper table: 180-280 mm,

Reading accurancy of adjustment indication: 0,01 mm.


SPEED

Shearing speed: 3-24 mm/s,

Slide closing speed: 120 mm/s,

Slide return speed: 135 mm/s.


POWER

Total power requirement: 97 kW.

Main drive: 75 kW.
