Press Trimming SE1-1200-1200x1400-1092

Price

Contact us for price

orCall +91 9920651051

Specifications

ManufacturerGodrej,India
ModelSE1-1200-1200x1400-1092
Year2002
ConditionUsed
Stock NumberMA1367
Item conditionDisassembled
Capacity tons1200

Description

Capacity : 1200 tons,

Rating point : 12 mm,

Stroke : 400 mm,

Slide adjustment : 200 mm,

Shut height from bolster : 700 mm,

Slide face (FB x LR ) : 1200 x 1200 mm,

Clear distance between oil trays : 1300 mm,

Height of bolster surface from ground : 900 mm,

Size of bolster : 1200 x 1400 mm,

Bolster thickness : 260 mm,

Speed in continuous mode : 16 spm,

Speed in once mode : 8 spm,

Available job energy including die cushion : 40000 mkg,

Main motor siemens make : 110/1500 kW/rpm,

Electric supply : 415+/-5%, 3 phase, 50 Hertz,

Air supply pressure : 5.5 bar moisture free air,

CBC capacity suitable for top tool weight of 1.5 ton,

Air consumption : 1200 min,

Hos travel : 20 mm,

Cushion pad size : 1000 x 1000 mm.

With Hydraulic overload safety.
