2 tons Hammer Drop Forging Open Die M1343 Stanko Russia

Capacity : 2 tons,

Nominal weight of falling parts : 2000 kg,

Strike energy : 50 kJ min.,

Number of ram strokes per minute : 56,

Maximum ram stroke : 1000 mm,

Clear distance between posts : 2360 mm,

Clear distance between guides : 550 mm,

Clear height of working area : 530 mm,

Distance from lower striker face to floor level : 750 mm,

Striker face dimensions :

Length : 530 mm,

Width : 300 mm,

Excess steam or air pressure : 0.6 – 0.8 MPa,

Permissible steam superheat temperature : 200 C,

Hammer overall dimensions :

Left to right : 4610 mm,

Front to back : 1930 mm,

Height above floor : 4960 mm,

Anvil weight : 30 tons,

Weight Hammer with anvil : 48 tons.
