Lathe Vertical Turning CNC Kolomna
or
Call +919920651051
Specifications
| Manufacturer | Kolomna |
| Condition | Used |
| Stock Number | MA3607 |
| Item condition | Good condition |
| Capacity tons | 5000 |
Description
Max working dia : 5000 mm,
Table diameter : 4500 mm,
Hydraulic clamping : 6,
C axe : yes,
Max table speed : 130 rpm,
Z stroke : 600 mm,
Rams : 2
Tools : ISO50,
Max height part : 2230 mm,
Main motor : 28 KW,
Chip conveyor : 1,
Max weight : 63 tons,,
External machine dimension : 6600 x 11400 x 8400 mm,
Machine Total weight : 145 tons.
